Shoreline's Green Street Project

City Experiments with
"Low Impact Development" Street Treatment Project
(This story is reprinted in Shoreline Area News
TODAY 12/7 http://www.shorelineareanews.com/2010/12/shorelines-green-street-project.html)

17th Ave NE is the site if the
Green Streets Project
in Shoreline

On a small neighborhood street between NE 145th and NE 150th on 17th Ave NE an extraordinary experiment is underway. This is the "Green Streets" project undertaken by Shoreline's Public Works and

Surface Water & Environmental Services.

Permeable Asphalt Pavement
Medium creates new sidewalk
photo credit-Janet Way

Green Streets is a Capital Improvement Project approved by the City Council in 2009, and implemented by the need to comply with the NPDES II (National Pollution Discharge Elimination  Standard) Permit required by the WA Department of Ecology.  This permit allows municipalities to operate their drainage systems. The latest permit is providing a very high standard that now surpasses the stormwater requirements of DOE, because City Council approved this newest Stormwater Code in 2009.

It is partially inspired by the now well known SEAstreets project in Seattle's Greenwood Neighborhood.

That original project was created in 2003, and has now achieved aclaim nationwide for its effectiveness in infiltrating stormwater, slowing traffic and providing an attractive neighborhood environment.

17th NE "AFTER"
Project Underway
photo credit - City of Shoreline

Now the Shoreline 17th Street Project is nearly completed. It features "bioswales" planted with native plantings in the Right of Way, "pervious" asphalt sidewalks and driveways, and an attractive "meandering" design which slows traffic. The pervious asphalt is underlain with a bed of prepared soil, as are the swales which absorb a large quantity of stormwater which would otherwise run quickly into the local stream. In this case it is Hamlin Creek, a tributary of Thornton Creek, which is already greatly stressed as an urban stream.  When the stormwater percolates into the ground in the bioswales or through the asphalt, it is cleaned naturally by the soils and plantings.

Here are some before and after shots provided by the Surface Water Environmental Services.

17th NE "BEFORE"
photo credit- City of Shoreline

The Street Edges shown before and after -

17th NE Right of Way street edge "BEFORE"
photo credit - City of Shoreline

Planted swale next to sidewalk section before
permeable asphalt applied
photo credit - City of Shoreline

One feature of the project was that some of the existing trees have been preserved, though some were

too impacted to be saved. The City met frequently with the neighborhood to address their concerns.

This huge Madrone tree was protected and reserved next to the sidewalk.
It had previously had a circular bed surrounding it
that covered part of the trunk.
Hopefully now it has more breathing room .
photo credit - JanetWay

One neighbor I spoke to today said she was happy with the sidewalks and the fact that traffic is now lessened and slowed down, but she was surprised how much of the area she'd thought was her yard was impacted. She also said she felt the project came out much differently than she'd expected. But, she also said that the stormwater DOES seem to be infiltrating well into the pavement and swales.

Section of 17th NE project adjacent to
the VFW Hall. This sidewalk appears to be
the typical concrete material.
photo credit-Janet Way

Here's hoping that this magnificent Madrone which is watching over the project

will thrive and the neighbors will as well! We look forward to the completion and the plantings
growing into their true potential to do their "water quality work".

Giant Madrone on 17th NE
photo credit- Janet Way
